| Engine |
| Engine Type (YAMAHA) |
MZ300L3U Single Cylinder, Forced Air Cooling, 4 Stroke Gasoline Engine |
| Displacement (cc) |
301 |
Rated Power
(ps/3600rpm) |
7.9 |
| Oil Volume (cc) |
1100 |
| Ignition System |
TCI (Transistor Controlled Ignition) |
| Fuel |
Unleaded Gasoline |
| Starting System |
Recoil, Electric Start |
|
|
|
| Generator |
| AC OUTPUT |
| Rated Output (KVA) |
4.0 |
| Maximum Output (KVA) |
4.5 |
| Rated Voltage (V) |
220 |
| Rated Frequency (Hz) |
50 |
| DC OUTPUT |
12V8.3A |
| General |
| Fuel Tank (L) |
25 |
| Length (mm) |
690 |
| Width (mm) |
550 |
| Height (mm) |
560 |
| Continuing Time (hr) |
82 |
| Net Weight (KG) |
10 |
|
| AUTOMATIC VOLTAGE REGULATOR (AVR) |
| PACIFIC`s AVR smoothes the fluctuating power output and enables the operation of sensitive electronic equipment. |
| OIL WARNING SYSTEM |
| PACIFIC`s answer to explosive repair bills. The warning system will automatically stop the engine when the oil drops below a predetermined level. |
| LARGE FUEL TANK |
| Large capacity of Fuel tank with Fuel meter. |
| DC OUTPUT CAPABILITY |
| Direct current output allows battery recharge. |
| RUGGED FILL-FRAME |
| Its protective frame guards the generator from rough handling and damage, and also makes it easy for transport. |
|
| |
 |
